Architecture / Decorative Glass To Glass Laminating Machine With EVA Film

1.0 set
MOQ
Architecture / Decorative Glass To Glass Laminating Machine With EVA Film
Характеристики Галерея Характер продукции Спросите цитату
Характеристики
Характеристики
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Bevera
Showroom Location: Egypt, Turkey
Condition: New
Machine Type: Glass Laminating Machine
Production Capacity: 107 square meter/cycle
Voltage: 220-440V
Power: 58KW
Dimension(L*W*H): 2960*4600*2150mm
Weight: 4300kg
Warranty: 1 Year
Key Selling Points: High Productivity
Name: Glass laminating machine with EVA film
Max glass size: 2000x3000mm
Glass thickness: 3-40mm
Application: Architecture/Decorative glass
Usage: Laninating Glass
Model: FD-J-5-4
Operation: Automaticlly
Control system: PLC Auto
Service: Overseas
Keyword: Non Autoclave PVB Laminated Oven
After Warranty Service: Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location: Egypt, Turkey, Russia
Сертификация: ce
After-sales Service Provided: Online support, Free spare parts, Field installation, commissioning and training, Video technical support
Основная информация
Сертификация: ce
Model Number: FD-J-5-4
Оплата и доставка Условия
Packaging Details: Wrapped with moisture proof film Wooden case suitbable for container loading
Supply Ability: 20 Set/Sets per Month
Характер продукции
Product Description
Fangding machine is unique in China.We have the most professional R & D, production, sales and after-sales team .For EVA glass laminating machine, we usually have specification 2000x3000mm, 2200x3200mm,2200x3660mm and 2440x3660mm.For different capacity, the design of two, three and four layers can be chosen.
The 4 layers machine divides into double independent system, the upper 2 layers as a independent system, lower 2 layers as another independent system. Each system can work independent, do not affect each other, that means you can do different kinds of glass at the same time, for example, do tempered laminated glass in upper system, do curved laminated glass in lower system.
Machine model
FD-J-5-4
Rated power
58KW
Processing glass size
Max:2440x3660mm
Max glass thickness 40mm
Floor space
L*W:4520*10500mm
Voltage
220V-440V
Working temperature
90degree--140degree
Efficiency
90-120min/cycle
Max production capacity:107 Sq.m/cycle
Direction for use
1. Prepare two pieces of glass sheets and same
size EVA film in the middle of the two pieces of glass.
2. Put the prepared glass sheets onto the tray
and then push into the furnace.
3. After the machine working for about 2
hours, pull out the trays, and cool the glass.
4. Get the glass out from the silicone bags.

  • Application

Machinable glass type: top grade decorative laminated glass(Such as marble paper laminated
glass, silk laminated glass, flower laminated glass, and so on), outdoor building laminated glass, bulletproof laminated glass,
armored glass, LED/PDLC laminated glass, etc.
Size Information
Model
Process glass size(mm)
Power
N.W
Dimension(mm)
Floor space(mm)
productivity（㎡/cycle）
FD-J-2-4
2000X3000X4 layers

38KW
3700kgs
2530x4000x2150
3720x9000
72
FD-J-3-4
2000X3000X4 layers

45KW
3900kgs
2730x4200x2150
4020x9500
84
FD-J-4-4

2000X3000X4 layers
52KW
4100kgs
2730x4600x2150
3720x10500
96
FD-J-5-4

2000X3000X4 layers
58KW
4300kgs
2965x4600x2150
4520x10500
107
Related Products
Packing&Shipping
We make strict Quality testing before packing by professional staff and engineer.
The machine packed with standard package, will be fixed firmly in the container.
It makes sure the machine arrived our customers’ factory with good condition.
After Sales Service
1.Your inquiry related to our products will be replied within 24 hours. Well-trained & experienced staff are to answer all your
inquiries in English.
2.OEM projects are highly welcomed. We have strong R&D team here to help you.
3.Your business relationship with us will be confidential to any other party.
4.Good after-sale service offered. When the equipment arrives at your factory, experienced engineers will go to install machine
and share our experiences in glass laminating over 17 years.
5.For more details, just contact us. We are pleased to help you in any way we can.
Company Introduction
Fangding Technology Co., Ltd. is a professional manufacturer of laminated glass machine and EVA film, the whole PVB laminating line for 17 years. Our laminated glass machine have been sold to 68 countries and regions, most import to Europe.Our equipment is self-development, and sales Top one in china. So we have rich experience in machine loading and delivery. Our company started from laminated glass factory, we have rich experience in laminated glass and can supply complete solution for our customers.

Our Services & Strength

Doing business based upon the tenets Quality, Innovation, Integrity and Value. With extensive glass laminating experience, Fangding Technology has earned one of the finest reputations in the industry. From major public to private facilities, the
glass made by our equipment has left their mark on a number of the most prestigious and beautiful buildings throughout all over the world.
FAQ
Q: Could your machines laminate bent tempered laminated glass?
Re: Yes. Our machines can laminate large-size bent tempered laminated glass in one step, which is very easy to operate.
Q: How many stages your machines can set?
Re: Normally we set 5 stages. It can be customized for you to 6 stages if needed.
Q: When will your machine ready for delivery after our prepayment?
Re: Normally within in 30 days.
Q: What about the terms of payment?
Re: Normally 30% prepayment, 70% before shipment by T/T. L/C and other terms are also available.
Q: Does you machine have any certifications?
Re: Yes, we do. Our machine has got CE/ISO9001/CCC/CSA/PC certificate.
Q: Could the laminated glass used for exterior?
Re: Yes. The laminated glass with super clear EVA can be totally used for exterior.
Q: How to operate the machine? Is it difficult?
Re: No, our machine is very easy to operate. The machine will work automatically after you set the parameters through the touch
screen. We send you operating manual with the machine, we also have video for operation for your reference.
